Unveiled: The Pioneering, Flexible High-Voltage Reed Relay in the Industry
New High-Voltage Reed Relay Range Launched by Pickering Electronics
Pickering Electronics, a renowned manufacturer of reed relays, has introduced a new customizable high-voltage reed relay range, the Series 600, in 2022. This innovative product offering is designed to cater to the increasing demand for tailored high voltage reed relays.
The Series 600 boasts over 2500 different combinations of rating and connection options, providing engineers with a vast array of choices to suit their specific requirements.
One of the standout features of the Series 600 is its industry-leading switch-to-coil isolation, which can reach up to 25kV. This high level of insulation resistance, over 1013 Ω, ensures minimal leakage and maximum isolation, making it ideal for high-voltage test and switching applications.
Each Series 600 relay undergoes rigorous testing, including dynamic contact wave-shape analysis, to ensure consistent quality. This meticulous testing process guarantees reliable operation and long life for these relays.
The Series 600 relays also offer further flexibility with the inclusion of coaxial or electrostatic screens for improved signal integrity and noise reduction. Internal or external mu-metal screening in Series 600 relays enables high packing densities with minimal magnetic interference.
For managing coil back EMF, optional diodes or Zener diodes are available. The Series 600 relays employ formerless coil construction and Pickering's patented SoftCenter technology for improved mechanical robustness.
Series 600 relays can switch voltages from 3.5kV up to 12.5kV and can handle switching power capabilities up to 200W. A wide range of case sizes, potting materials, and contact forms can be specified to meet thermal, mechanical, or environmental constraints.
The Series 600 employs a modular design architecture that allows engineers to precisely specify their required rating parameters and connection options. This modular design, combined with the extensive range of options, makes the Series 600 a versatile solution for a variety of industries.
Applications for the Series 600 relays include hi-pot testers, power and signal cable testers, EV BMS and charge point testing, inverter or insulation resistance testing in solar energy systems, isolation in medical equipment, and high voltage switching and signal control for instrumentation.
Pickering Electronics' reputation for reed relay innovation is founded on decades of manufacturing excellence. The Series 600 is testament to this commitment to quality and innovation, offering a reliable and customizable solution for high-voltage applications.
Application-specific performance testing can be provided for Series 600 relays, ensuring that they meet the exacting standards of even the most demanding applications. With the Series 600, Pickering Electronics continues to push the boundaries of reed relay technology, offering engineers a versatile and high-performing solution for their high-voltage needs.
